Installing Hardware 1-4
8 Telephone Answering Device connector (TAD)
Provides a monaural connection from a standard voice modem, and transmits
microphone signals to the modem.
9 CD Audio connector (CD_IN)
Connects to the Analog Audio output on a CD-ROM or DVD-ROM drive using a
CD audio cable.
10 AUX In connector (AUX_IN)
Connects to internal audio sources such as TV Tuner, MPEG, or other similar cards.
11 Internal SB1394/FireWire port*
Connects to the SB1394/FireWire connector on the Audigy 2 Drive.
12 CD SPDIF connector (CD_SPDIF)
Connects to the SPDIF (Digital Audio) output (where available) on a CD-ROM or
DVD-ROM drive using the Digital CD audio cable provided.
13 Joystick/MIDI connector (JOYSTICK)*
Connects to the Joystick/MIDI cable.
14 Audio Extension connector (AD_EXT)
Connects to the internal Audigy 2 Drive (upgrade option).
Table 1: Description of Jacks, Connectors and Ports.
Number Description
Click here or on any description in
the table to return to the main
diagram.
*Available with some models of
the Sound Blaster Audigy 2 card.
