Mounting and Cable Routing Procedures for Dell™ Digital KVM’s (1082DS, 2162DS, 4322DS)
Page 11
4.2
Server Interface Pod Matrix
Tables 3 & 4 below show information about Dell Server Interface Pods (SIPs). If the table shows the
EDID resolution is hardcoded, the maximum resolution the SIP reports to the OS cannot be changed
from 1024x768 for the Local Port.
Acronyms:
Extended Display Identification Data (EDID)
Display Data Channel (DDC)
Table 3: Server Interface Pod Matrix 4:3 Resolutions
SIPS
EDID
Resolution
Hard Coded
4:3 Resolutions Capable
USB Speed
CAC
Support
1024x768
1280x1024
1280x1024
1600x1200
FS
HS
PS/2
SIP
1024x768
Y
Y
+
Y
+
Y
+
N/A
N/A
N
USB
1.1 SIP
1024x768
Y
Y
+
Y
+
Y
+
N/A
N/A
N
USB
2.0 SIP
1024x768
Y
Y
+
Y
+
Y
+
‐
Y
N
USB
2.0 +
CAC
SIP
User
Selectable
Y
Y
Y
Y
Y
‐
Y
+
Requires the user to enable showing unsupported resolutions via the target computer’s video
adapter settings (effectively ignoring the DDC/EDID).
Table 4: Server Interface Pod Matrix 16:10 Resolutions
SIPS
EDID
Resolution
Hard Coded
16:10 Resolutions Capable
USB
Speed
CAC
Support
800x500 1024x640 1280x800 1440x900
1680x1050 FS
HS
USB
2.0 +
CAC SIP
User
Selectable
Y
Y
Y
Y
Y
Y
‐
Y
