Response time

25-ms rise (typical)
35-ms fall (maximum)

Refresh rate

60 Hz

Operating angle

0º (closed) to 180°

Viewing angles:



Horizontal

±40°

Vertical

+10°/–30°

Pixel pitch

0.28 x 0.28 mm (XGA)
0.20 x 0.20 mm (SXGA+)

Power consumption:



Panel with backlight (typical)

6.5 W (XGA)
7.0 W (SXGA+)

Controls

brightness can be controlled through keyboard
shortcuts



Keyboard

Number of keys

87 (U.S. and Canada); 88 (Europe); 91 (Japan)

Key travel

2.7 mm ± 0.3 mm (0.11 inch ± 0.016 inch)

Key spacing

19.05 mm ± 0.3 mm (0.75 inch ± 0.012 inch)

Layout

QWERTY/AZERTY/Kanji



Touch Pad

X/Y position resolution (graphics table mode)


240 cpi

Size:



Width

64.88-mm (2.55-inch) sensor-active area

Height

48.88-mm (1.92-inch) rectangle



Track Stick

X/Y position resolution (graphics table mode)


250 count/sec @ 100 gf

Size

protrudes 0.5 mm higher than surrounding keycaps



Battery

Type

standard 6-cell "smart" lithium ion (48 WHr)
4-cell "smart" lithium ion (32 WHr)

Dimensions:



Depth

77.5 mm (3.05 inches)

Height

19.1 mm (0.75 inch)

Width

123.4 mm (4.86 inches)

Weight

0.32 kg (0.7 lb) (6

-cell battery)

0.23 kg (0.52 lb) (4

-cell battery)

Voltage

11.1 VDC (6-cell battery)
14.8 VDC (4-cell battery)

Charge time with computer off (approximate)

1 hour for 80% charge of battery

Operating time

varies depending on operating conditions; can be
significantly reduced under certain

power-intensive

conditions

See "

Using a Battery

" for more information on battery

life.

Life span (approximate)

300 discharge/charge cycles

Temperature range:



Operating

to 35°C (32° to 95°F)

Storage

–20°

to 65°C (–4° to 149°F)



AC Adapter

Input voltage

90–264 VAC
