Page 20
18
Tower-to-Rack Conversion Guide
Figure 1-7.
Installing the Control Panel Assembly
1
M3 x 12 T10 Torx panhead
screw (2)
2
display module
3
display module cable
4
control panel board
5
M3 x 5 T10 Torx panhead
screw (3)
6
control panel cable
7
system chassis
8
display module label
5
6
4
2
3
7
8
1
book.book Page 18 Friday, May 26, 2006 3:03 PM
