A REFERENCE GUIDE FOR OPTIMIZING DELL™ POWERVAULT™ MD1XXX FAMILY SAS SOLUTION

VER A02

PAGE 8

6/16/2008

Perform periodic physical inspection of your connections and cabling

Damaged cables and loose connections may cause functional issues with your storage solution.
Dell recommends a physical equipment audit two times a year or anytime after re-cabling or re-
deploying your storage hardware.

3. Dell SAS Product Offering

The PowerVault MD1xxx Family enclosures represent Dell JBOD offering. This includes both the
MD1000 and MD1120 enclosures (see Table 2). These are feature-optimized storage expansion
enclosures that use the latest industry standard storage interconnect technology, Serial Attached
SCSI (SAS). These enclosures support between 2 and 24 physical SAS drives. Along with Dell
host-based RAID controllers, PERC 5/E and PERC 6/E, the PowerVault MD1xxx Family
introduces new levels of performance, capacity, and scalability at industry leading prices.

Table 2: Summary and comparison of key features of the MD1xxx Family enclosures

Features

PowerVault MD1000

PowerVault MD1120

Rack space

3U (rack only)

2U (rack only)

Drive bays

15 (3.5-inch drives)

24 (2.5-inch drives)

Supported drive types

3 Gbps SAS & 3 Gbps SATA II

3 Gbps SAS

Expandability

Three shelves for a total of 45
drives per host port (unified
mode only)

Three shelves for a total of 72
drives per host port (unified
mode only)

Management

In-band, using Dell
OpenManage software

Backplane options

Unified or split JBOD

Supported RAID
controllers

PERC 5/E and PERC 6/E

PERC 6/E only

Cluster support

No No

Hot-pluggable drives

Yes Yes

Hot-pluggable fans and
power supplies

Yes (combined fan and power
supply modules)

Yes (combined fan and
power supply modules)

Enclosure management
configurations

Redundant and nonredundant

Redundant and
nonredundant

Fan and power supply
configuration

Redundant Redundant

Supported disk array
enclosures

PowerVault MD3000 and
PowerVault MD3000i

N/A

(designed for future

support for attachment to

external RAID enclosures)
