Quadport Capable Hardware for the M1000e Modular Chassis
Page 26
Blade 3
Device IOM A1 IOM B1 IOM C1 IOM C2 IOM B2 IOM A2
LOM 1 3
LOM 2 3
LOM 3 11
LOM 4 11
Fabric B1 Port 1 3
Fabric B1 Port 2 3
Fabric B1 Port 3 19
Fabric B1 Port 4 19
Fabric C1 Port 1 3
Fabric C1 Port 2 3
Fabric C1 Port 3 19
Fabric C1 Port 4 19
Fabric B2 Port 1 11
Fabric B2 Port 2 11
Fabric B2 Port 3 27
Fabric B2 Port 4 27
Fabric C2 Port 1 11
Fabric C2 Port 2 11
Fabric C2 Port 3 27
Fabric C2 Port 4 27
