Hard Drive(s)
Procedure
1 If you are removing the primary hard-drive, disconnect the power and data
cables from the primary hard-drive.
2 If you are removing the secondary hard-drive:
a Disconnect the power cable from the primary and secondary
hard-drives.
b Disconnect the data cable from the secondary hard-drive.
NOTE:
If you are not replacing the hard drive at this time, disconnect the other end
of the data cable from the system board connector and set it aside. You can use the
data cable to install a hard drive at a later time.
3 Remove the screws that secure the hard-drive assembly to the
hard-drive bay.
CAUTION:
Ensure that you do not scratch the hard drive’s circuit board, while
removing or replacing the hard drive.
4 Lift the hard-drive assembly away from the computer.
