82 Palm Rest Assembly
4 Connect the touch pad cable, LVDS cable, and Media Card Reader cable
to the connectors on the system board.
5 Replace the status light board (see "Replacing the Status Light Board" on
page 76).
6 Replace the display assembly (see "Replacing the Display Assembly" on
page 73).
7 Replace the power button board (see "Replacing the Power Button Board"
on page 68).
8 Replace the keyboard (see "Replacing the Keyboard" on page 57).
9 Replace the center control cover (see "Replacing the Center Control
Cover" on page 52).
10 Replace the five screws that secure the palm rest assembly to the computer
base.
11 Replace the compartment door (see "Replacing the Compartment Door"
on page 16).
12 Replace the battery pack (see "Replacing the Battery Pack" on page 14).
13 Replace any cards or blank that you removed from the 9-in-1 Media Card
Reader.
CAUTION: Before turning on the computer, replace all screws and ensure that no
stray screws remain inside the computer. Failure to do so may result in damage to
the computer.
