16 LAN-USB Cable
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in
"Before You Begin" on page 7. For additional safety best practices information,
see the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.
Removing the LAN-USB Cable
Prerequisites
1 Remove the battery. See "Removing the Battery" on page 13.
2 Remove the keyboard. See "Removing the Keyboard" on page 15.
3 Remove the base cover. See "Removing the Base Cover" on page 19.
4 Follow the instructions from step 1 to step 2 in "Removing the Optical Drive" on
page 27.
5 Remove the palm rest. See "Removing the Palm Rest" on page 39.
6 Remove the LAN board. See "Removing the LAN Board" on page 49.
