Internal Card With Bluetooth® Wireless Technology
Dell™ Inspiron™ 6400/E1505 Service Manual
Removing the Card
1.
Follow the instructions in
Before You Begin
.
2.
Use a plastic scribe to pry the card door open.
3.
Disconnect the card cable connector from the card, and remove the door with the card from the computer.
4.
Slide the card out of the plastic brackets.
Replacing the Card
1.
To replace the card, connect the card to the cable, then insert it into the compartment.
2.
Replace the card door by inserting the small center tab into the notch at the base of the compartment, and snap it into place.
3.
Replace the battery.
CAUTION:
Before you perform the following procedures, follow the safety instructions in the Product Information Guide.
NOTICE:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as the back panel) on the computer.
NOTICE:
To avoid damaging the system board, you must remove the main battery (see
Before Working Inside Your Computer
) before you begin
working inside the computer.
NOTE:
If you ordered an internal card with Bluetooth wireless technology with your computer, the card is already installed.
NOTE:
Ensure that you have removed the main battery for access to the card.
1 card door
2 card cable
connector
3 internal card with Bluetooth wireless
technology
4 plastic brackets
(2)
