Upgrading Your 39160 SC SI Card Firmware 1-3
7 Change the IP address on the network adapter of the client system to 10.40.10.1, the
subnet mask to 255.255.255.0, and the gateway to 10.40.10.1:
a From the desktop of the client system, right-click My Network Places and select
Properties.
b In the Network and Dial-up Connections window, right-click the network
interface controller that you connected to the NAS system with the crossover
cable in step 1.
c Click Properties.
d In the Local Area Connection Properties window, click Internet Protocol
(TCP/IP), and then click Properties.
e Click Use the following IP address.
f For IP address, type 10.40.10.1.
g For Subnet mask, type 255.255.255.0.
h For Default Gateway, type 10.40.10.1.
i Click OK, and then click OK to close the Local Area Connection Properties
window.
j If you are prompted to reboot the client system, click No.
8 Create a share for the SCSI firmware:
a If you are not already logged in, log in to the client system with an account that
has administrator privileges.
b Download the new SCSI firmware and utilities from support.dell.com and place
them in a directory on your client system.
Ensure that both 39160.rom and flash4.exe are downloaded to this directory.
c Double-click My Computer and browse to the directory where you downloaded
the firmware.
d Right-click this directory, and select Sharing.
e Click Share this folder.
f Type SCSI for the name of the share, and then click OK to confirm the share
settings.
9 Install the Dell Reinstallation Console from the Resource CD:
a Insert the Resource CD into the CD drive of your client system.
The Dell PowerVault 725N Resource CD window displays in a browser window.
NOTE: If the CD does not run automatically, double-click the start.bat file on the CD.
