Dell Vostro V130 (Late 2010) - Manual (Page 59)

Subscriber Identity Module (SIM) Board
Removing The Subscriber Identity Module (SIM) Board
1. Follow the procedures in Before Working On Your Computer .
2. Remove the Secure Digital (SD) card .
3. Remove the base cover .
4. Remove the battery .
5. Remove the SIM card .
6. Disconnect the SIM-board cable from the system board.
7. Remove the screws that secure the SIM board to the computer.
8. Gently peel the SIM-board data cable off the metal bracket on the computer.
9. Lift the SIM board and the SIM-board data cable up and away from the computer.
59
