Installing The Thermal Fan
NOTE: To remove or locate the heat sink and fan assembly, see Removing the Thermal Fan .
1. Place the fan into its slot on the computer.
2. Replace and tighten the screw to secure the fan to the computer.
3. Connect the thermal fan cable to the system board.
4. Install the system board .
5. Install the coin cell battery .
6. Install the card-reader board .
7. Install the keyboard .
8. Install the memory .
9. Install the LED cover .
10. Install the wireless wide area network (WWAN) card .
11. Install the wireless local area network (WLAN) card .
12. Install the audio board and the hard drive .
13. Install the battery .
14. Install the base cover .
15. Install the Secure Digital (SD) card .
16. Follow the procedures in After Working Inside Your Computer .
