Page 53
Display Closure Sensor
Removing The Display Closure Sensor
1.
Before Working On Your Computer
2.
Remove the
3.
Remove the
4.
Remove the
.
5.
Disconnect and release the flex cable that connects the display closure sensor board to the system board.
6.
Remove the screws that secures the display closure sensor to the computer.
7.
Lift the display closure sensor up and away from the computer along with its flex cable.
NOTE: To install the display closure sensor, see
Installing The Display Closure Sensor
53
