C2665dnf Color Laser Multifunction Printer | Dell Document Hub
Quick Reference Guide
October 2013
Front and Rear View
1
Duplex Automatic Document Feeder (DADF) 13 Operator Panel
2
Transfer Belt Unit
14 Top Cover
3
Drum Cartridge
15 Ethernet Port
4
Waste Toner Box
16 USB Port
5
Power Switch
17 Wireless Adapter Socket
6
Right Side Cover
18 Phone Connector
7
Tray1
19 Wall Jack Connector
8
Optional 550-Sheet Feeder (Tray2)
20 Left Side Cover
9
Multipurpose Feeder (MPF)
21 2nd Belt Transfer Roller (2nd BTR)
10 Toner Cartridge
22 Fusing Unit
11 Front Cover
23 Power Connector
12 Front USB Port
24 Rear Cover
1
14
2
3
4
6
5
7
8
9
10
13
11
12
20
15
16
17
18
19
21
22
23
24
Service Tag
Service Tag Express Service Code
xxxxxxx
000 000 000 00
