Dell PowerEdge C6220 II - Manual (Page 28)

28
FILE LOCATION: D:\Projects\User
Guide\Server\Dell\C6220II\BMC\C6220II_BMC_HOM_section1.fm
Batteries
Select Batteries from the Sensor Type drop-down menu to view the status of
the server system board battery.
Input Wattage Column Shows the power supply peak watt.
Maximum Wattage Column Shows the power supply maximum watt.
Firmware Version Column
Shows the firmware version.
Refresh Button Use this button to refresh the power supply
information.
Table 1-15. Batteries Sensor Readings
Item Description
General Settings For more information on this option, see Table 1-12.
Probe List
Status Column Shows the system board CMOS coin-cell battery status.
Probe Name Column Shows the name of the battery sensor.
Table 1-14. Power Supplies Sensor Readings
Item Description
