Table 1-17. Temperature Sensor Readings
Items
Description
General Settings
For more information on this option, see Table 1-12.
Probe List
Status Column
Displays the status of the temperature sensor.
Probe Name Column
Displays the temperature sensor name.
Typical temperature probes:
• MEZZ1 Temp
• CPU1 Temp
• CPU2 Temp
• DIMM ZONE 1 Temp
• DIMM ZONE 2 Temp
• PCH Temp
• Inlet Ambient Temp
Reading Column
Displays the temperature sensor reading.
Lower Non-Recoverable
Column
Displays the temperature sensor lower non-recoverable
threshold.
Lower Critical Column
Displays the temperature sensor lower critical threshold.
Lower Non-Critical
Column
Displays the temperature sensor lower non-critical
threshold.
Upper Non-Critical
Column
Displays the temperature sensor upper non-critical
threshold.
Upper Critical Column
Displays the temperature sensor upper critical
threshold.
Upper Non-Recoverable
Column
Displays the temperature sensor upper non-recoverable
threshold.
Refresh Button
Use this button to refresh the temperature sensor
reading.
