Oracle Database Migration to Dell PowerEdge 12 th Generation Servers and Dell Compellent Storage
Systems
14
Table 3. Volume configuration of the target database
Used for Volume Size File system
format ASM disk name
Oracle RAC
Clusterware disks 3 volumes of OCR
disks 1 GB each Block device N/A
2 volumes of
Voting disks 1 GB each Block device N/A
Oracle database 6 volumes for data
area 100 GB each ASM data7; data8;
data9; data10;
data11; data12
6 volumes for
Flash Recovery
Area (FRA) 100 GB each ASM fra7; fra8; fra9;
fra10; fra11; fra12
1 volume for spfile
of ASM instance 1 GB Block device N/A
The high level steps to prepare the target system include:
1. Create volumes in the Compellent storage and map to the target servers (PowerEdge R720).
2. Perform zoning in the Brocade switches to associate the Dell PowerEdge R720 servers’ WWN’s with
the Compellent front-end ports WWN’s.
3. Create volume partitions on the two PowerEdge R720 servers.
4. Configure DM Multipath to the volumes on the two PowerEdge R720 servers.
5. Stamp the volumes as ASM disks on the two PowerEdge R720 servers. Again, ASM disks need to
have different names as the source database or data migration does not work later. The screen
output of the service oracleasm listdisks command is shown below.
# service oracleasm listdisks
DATA10
DATA11
DATA12
DATA7
DATA8
DATA9
FRA10
FRA11
FRA12
FRA7
FRA8
FRA9
6. Install Oracle RAC Clusterware 11.1.0.7 on the two PowerEdge R720 servers.
7. Install Oracle Database 11.1.0.7 binary on the two PowerEdge R720 servers.
8. Use the Oracle tool Database Configuration Assistant (DBCA) to create the Oracle ASM instance
without creating the database instance. In Oracle release 11.1.0.7, the creation of the ASM
instance and the creation of the database instance are combined in the DBCA tool. Once ASM
