Re pl a c i n g Par t s 83
NOTICE: If you need to install memory modules in two connectors, install a
memory module in the connector labeled "JDIM (DIMMA)" before you install a
module in the connector labeled "JDIM2 (DIMMB)."
8 Ground yourself and install the new memory module:
HINT: If the memory
module is not installed
properly, the computer
does not boot. No error
message indicates this
failure.
a Align the notch in the module with the slot in the center of the
connector.
b Slide the edge of the module firmly into the connector, and rotate
the module down until you hear a click. If you do not hear the
click, remove the module and reinstall it.
memory module
securing clip
