PAGE 21
TM201F7U
Items Specifications
Size (diagonal) 20.1 inch
High Brightness
High Contrast
Wide Angle of View
High Speed Response
Long Lamp Life
Recommended Resolution 640X480
Pixel Pitch 0.6375mm(H) X0.6375mm (V)
Number of Dots 640XRGBX480
Viewable Area 408mm(H) x306mm (V)
LCD Panel
Colour Display 16.7million
Colour System NTSC
Sound System M
PC Qualified Input Format VGA/SVGA
YPbPr Input Format
480i, 480P, 576i, 576P, 720P, 1080i, 1080P(50Hz、
60Hz)
Audio Output Consumption 2x2.0w
AV-Audio Input One way(S-Video is using in community)
AV-Video Input One way
Earphone Output One way
PAL/NTSC Digital Comb Filter YES
S-Video Input One way
YPbPr Input One way(with audio input)
VGA Video Input One way
VGA Audio Input One way
Voltage Input
Rated Power Consumption
Please refer to the back label
Standby Power Consumption ≤1.5W
Unit Dimension
590mm（W）×435mm(H)×230mm(D)
（including the pedestal）
Unit Weight 10kg(Approx.)
SPECIFICATIONS
