Specifications – Changhong Electric TM201F7U User Manual
Page 22
PAGE 20
W170F7U
Items Specifications
Size (diagonal)
17.1 inch
High Brightness
High Contrast
Wide Angle of View
High Speed Response
Long Lamp Life
Recommended Resolution
1280X768
Pixel Pitch
0.291mm(H) X0.291mm (V)
Number of Dots
1280XRGBX768
Viewable Area
372.48mm(H) x223.488mm (V)
LCD Panel
Colour Display
16.7million
Colour System
NTSC
Sound System
M
PC Qualified Input Format VGA/SVGA/XGA/WXGA
YPbPr Input Format
480i, 480P, 576i, 576P, 720P, 1080i, 1080P(50HZ、
60HZ)
Audio Output Consumption
2x2.0W
AV-Audio Input
One way(S-Video is using in community)
AV-Video Input
One way
Headphone Output
One way
PAL/NTSC Digital Comb Filter
YES
S-Video Input
One way
YPbPr Input
One way(with audio input)
VGA Video Input
One way
VGA Audio Input
One way
Voltage Input
Rated Power Consumption
Please refer to the back label
Standby Power Consumption
≤1.5W
Unit Dimension
525mm（W）×350mm(H)×230mm(D)
（including the pedestal）
Unit Weight
7.5kg(Approx.)
SPECIFICATIONS
