Installing Enclosure Components
47
Installing the Backplane
1 Align the holes on the backplane with the holes on the enclosure.
2 Tighten the captive screw to secure the backplane to the chassis.
See Figure 3-14 for PowerVault MD1200 or Figure 3-15 for
PowerVault MD1220.
3 Replace the screws that secure the backplane to the chassis.
See Figure 3-14 for PowerVault MD1200 or Figure 3-15 for
PowerVault MD1220.
4 Align the slots on the EMM/power supply cage with the tabs on the
5 Push the EMM/power supply cage toward the front of the enclosure.
6 Replace the screws that secure the EMM/power supply cage to the chassis.
7 Replace the control panel. See "Installing the Control Panel" on page 44.
8 Replace the power supply/cooling fan modules. See "Installing a Power
Supply/Cooling Fan Module" on page 41.
9 Replace the hard drives. See "Installing a Hard Drive" on page 32.
10 Connect all the cables to the enclosure.
11 Turn on the enclosure and the host server.
