24

M5424 SAN I/O Module Hardware Reference Manual

53-1001082-01

Removing and replacing the SAN I/O Module

3

FIGURE 6

Removing an SFP from a Port

5. Refer to the Hardware Owner’s Manual for the Blade Server Enclosure to remove and replace

the SAN I/O module from the enclosure.

.

ATTENTION

If you are not replacing the SAN I/O Module, use a filler panel to fill the empty slot to maintain proper
air flow. Do not leave the slot empty.

SFP

Bale

3

1

Cable

Release

2

SFP

4
