Dell Latitude ST (Late 2011) - Manual (Page 62)

Video
Video controller Intel HD Graphics 600
Video memory 766 MB
Communications
Network adapter one RJ-45 connector support via docking station
Wireless
• Wireless On/Off functionality
• WWAN and Global Navigation Satellite Systems
(GNSS)
• Wi-Fi
Ports and Connectors
Audio one microphone connector/stereo headphone/speakers
connector
Video one 19-pin HDMI connector
USB one 4-pin USB 2.0 compliant connector
Memory card reader one 3-in-1 memory card reader
Display
Type WXGA IPS LED
Size 10.1 inches high definition (HD)
Dimensions:
Height 135.60 mm (5.34 inches)
Width 216.96 mm (8.54 inches)
Diagonal 255.85 mm (10.07 inches)
Active area (X/Y) 216.96 mm / 135.60 mm
Maximum resolution 1280 x 800 pixels
Maximum brightness 340 nits
Refresh rate 60 Hz
Minimum viewing angles:
Horizontal +/- 80°
Vertical +/- 80°
Pixel pitch 0.1695 mm x 0.1695 mm
Battery
Type (30WHr) 4–cell lithium ion
Dimensions
62
