wizard. When the privileged users list is populated, all
administrator users that are not a part of this list
cannot access the storage array and manage the LUNs
that are created.
Default time for
scheduling task when idle
is 10 minutes and cannot
be reset The value for Schedule Task When Idle cannot be set
to a different value. The value you enter is not retained
and the default value—10 minutes—is used. This is a known issue.
Enabling Single Instance
Storage (SIS) on the first
volume disables SIS on
the subsequent volumes When you enable SIS on the first volume using the
Advanced tab of the Volume Properties window, SIS
is disabled on subsequent volumes and no error
message is displayed. To work around this issue, run the following command from the
command prompt to fully enable the SIS features: sisadmin /i
When you enable SIS on subsequent volumes through the Graphical
User Interface (GUI), the SIS service is stopped. You must restart the
SIS service manually through the services.msc application for each
volume.
For more information, see Knowledge Base article 913109 on the
Microsoft Support website at support.mircosoft.com.
Limitations while creating
private LUNs with the
PowerVault MD3000 array When you are creating a LUN, though you select the
This Server only option in Provision Storage®
Server
Assignment, the LUN is assigned to all nodes in the
cluster.
You can create Private LUNs manually only using the Dell PowerVault
Modular Disk Storage Manager. For more information see the Dell
PowerVault Modular Disk Storage Manager User's Guide located on the Dell
support website at support.dell.com.
Storage Provision wizard
fails when formatting a
volume less than 8 MB When you create a volume on a LUN of less than 8 MB
using the Storage Provision wizard, the volume
cannot be formatted. This is a known issue.
Error message is
displayed when you start
or stop the NFS service When you try to start or stop the User Name Mapping,
Client for NFS, or Server for NFS service from the
Microsoft Service for NFS, the following error message
is displayed: Unspecified user. This feature is working as designed. To perform this action, you must
log in as an administrator.
The PowerVault MD3000
storage array is labeled
as Fiber Channel in the
Storage Provision wizard In the Storage Provision wizard, the PowerVault
MD3000 storage array is labeled as Fiber Channel even
though it is not a Fiber Channel connection. This is a known issue.
Dell Initial Configuration
Tasks wizard or
PowerVault NX1950
Management Console
does not start after Dell
Storage Initialization
Wizard has initialized This issue occurs because the Dell Storage
Initialization Wizard encountered an error condition
and exited before completing the configuration. In
certain cases, the error message disappears from the
screen without user interaction. This is a known issue. To resolve this issue, call Dell Technical Support.
The Dell OpenManage™
Help window in the
PowerVault NX1950
Configuration
Tasks Wizard appears in
English irrespective of the
language setting
The Dell OpenManage™ Help window is displayed in
English and not in the language of the selected
environment such as French, German, Japanese,
Korean, Simplified Chinese, Spanish, or Traditional
Chinese. This is a known issue.
Dell Storage
Initialization Wizard may
stop responding Dell Storage Initialization Wizard may stop
responding if the desktop is locked while Dell Storage
Initialization Wizard is configuring the system. Perform the following steps:
1. Terminate the Dell Storage Initialization Wizard application
using the Windows Task Manager.
2. Restart the Dell Storage Initialization Wizard from the
PowerVault NX1950 Management Console. Click Start® All
Programs® Administrative Tools® Windows Unified Data
Storage Server.
Microsoft error reporting
displays Dell Storage
Initialization Wizard
application errors
NOTE: This error occurs if you exit the Dell Storage
Initialization Wizard while it is running.
Microsoft Error Reporting displays the following
application error message while using the Dell Storage
Initialization Wizard:
Some unexpected errors have happened to the
software you recently used
To workaround this issue, run the Dell Storage Initialization wizard
completely without interruption.
Enabling Windows
Firewall The following ports must be open:
l UDP port = 80: http
l UDP port = 111: Portmap UDP
l UDP port = 1048: NFS MountUDP
l UDP port = 2049: NFS Server UDP
l UDP port = 1047: NFS Lock UDP
l UDP port = 1039: NSM UDP
l UDP port = 162: SNMP
l UDP port = 2162: Array Init 1
l UDP port = 2163: Array Init 2
l UDP port = 137: NetBIOS Name Service
l UDP port = 138: NetBIOS Datagram Service
l TCP port = 80: IIS
l TCP port = 135: RPC
l TCP port = 3260: ISCSI
l TCP port = 111: Portmap TCP
l TCP port = 1048: NFS Mount
l TCP port = 2049: NFS Server TCP
l TCP port = 1047: NFS Lock
For download instructions and location of the firewall script, see the Dell
PowerVault NX1950 Systems Deployment Guide located on the Dell
Support website at support.dell.com.
NOTE: Ensure that adequate security precautions are in place before
proceeding with the workaround for this issue.
