Optical Drive
Dell™ Vostro™ 230 Service Manual— Mini Tower
Removing the Optical Drive
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the cover .
3. Remove the front bezel .
4. Disconnect the power and data cables from the optical drive.
5. Remove the screws that secure the optical drive to the computer.
6. Slide the optical drive out through the front of the chassis and remove the drive from the computer.
Replacing the Optical Drive
To replace the optical drive, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe® Flash® Player from Adobe.com in order to view the illustrations below.
