Cover
Dell™ Vostro™ 230 Service Manual— Mini Tower
Removing the Cover
1. Follow the procedures in Before Working Inside Your computer .
2. Remove the thumb screws that secure the cover to the computer.
3. Release the cover by sliding it away from the front of the computer.
4. Lift and remove the cover from the computer.
Replacing the Cover
To replace the cover, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe® Flash® Player from Adobe.com in order to view the illustrations below.
