Dell Precision M4800 (Late 2013) - Manual (Page 80)

Table 31. Contactless Smart Card
Feature Specification
Supported Smart Cards and
Technologies
• ISO14443A — 160 kbps, 212 kbps, 424 kbps, and 848 kbps
• ISO14443B — 160 kbps, 212 kbps, 424 kbps, and 848 kbps
• ISO15693
• HID iClass
• FIPS201
• NXP Desfire
Table 32. Physical Dimension
Physical M4800 M6800
Height:
Touch
• Front: 36.1 mm (1.42
inches)
• Back: 40.2 mm (1.58
inches)
Non-touch
• Front: 32.9 mm (1.29
inches)
• Back: 36.7 mm (1.44
inches)
• Front: 33.1 mm (1.30
inches)
• Back: 37.2 mm (1.46
inches)
Width 376 mm (14.80 inches) 416.70 mm (16.40 inches)
Depth 256 mm (10.07 inches) 270.60 mm (10.65 inches)
Weight (Minimum) 2.89 kg (6.38 lb) 3.58 kg (7.89 lb)
Table 33. Environmental
Feature Specification
Temperature range:
Operating 0 °C to 40°C (32 °F to 104°F)
Storage –40 °C to 65 °C (–40 °F to 149 °F)
Relative humidity (maximum):
Operating 10 % to 90 % (non-condensing)
Storage 5 % to 95 % (non-condensing)
Maximum vibration:
Operating 0.66 GRMS, 2 Hz - 600 Hz
Storage 1.3 GRMS, 2 Hz - 600 Hz
Maximum shock:
Operating 140 G, 2 ms
80
