Installing the coin-cell battery, Removing the palmrest – Dell Precision M4800 (Late 2013) User Manual
Page 29
Installing the Coin-Cell Battery
1.
Replace the coin-cell battery in its slot in the computer.
2.
Connect the coin-cell battery cable.
3.
Install the:
a) base cover
b) battery
4.
Follow the procedures in
After Working Inside Your Computer
.
Removing the Palmrest
1.
Follow the procedures in
Before Working Inside Your Computer
.
2.
Remove the:
a) battery
b) base cover
c) keyboard trim
d) keyboard
e) optical drive
f) hard drive
3.
Disconnect the RFID and fingerprint reader cables. Remove the screws which secure the palmrest to the computer.
29
