Replacing the Display Bezel
1. Follow the instructions in Before You Begin .
2. Route the Mini-Card antenna cables and the display cable on the display hinges.
3. Realign the display bezel over the display panel, and gently snap into place.
4. Replace the display assembly (see Replacing the Display Assembly ).
Display Panel
Removing the Display Panel
1. Follow the instructions in Before You Begin .
2. Remove the display assembly (see Removing the Display Assembly ).
3. Remove the display bezel (see Removing the Display Bezel ).
4. Disconnect the camera cable from the connector on the camera module.
5. Remove the six screws that secure the display panel to the display cover.
6. Lift the display panel off the display cover.
7. Turn the display panel over and place it on a clean surface.
8. Lift the tape that secures the display cable to the display-board connector and disconnect the display cable.
9. Remove the camera cable.
1 display bezel 2 display hinges (2)
1 display panel 2 screws (6)
3 display cover 4 camera cable connector
NOTE: The camera cable is affixed to the back of the display panel.
