Removing the I/O Board | 59
4 Lift the connector latch and pull the pull-tab to disconnect the ribbon cable from
the I/O-board connector.
5 Lift the I/O board away from the computer base.
1 I/O board 2 connector latch
3 pull-tab 4 ribbon cable
4
3 2 1
