4. Command List
s/n Command Description Protocol
1
2 POWER ON
POWER OFF POWER ON
POWER OFF EFBE10000329ED1111000100
EFBE100003E82D1111000101
3
4
5
6 UP
DOWN
LEFT
RIGHT EFBE10000369EC1111000103
EFBE100003282E1111000104
EFBE100003E9EE1111000105
EFBE100003A9EF1111000106
7
8
9
10
11 MUTE
CH UP
CH DOWN
VOL UP
VOL DOWN TURN ON / OFF AUDIO
CHANNEL UP
CHANNEL DOWN
VOLUME UP
VOLUME
DOWN
EFBE100003282B1111000108
EFBE100003A9EA111100010A
EFBE100003682A111100010B
EFBE10000329E8111100010C
EFBE100003E828111100010D
12
13
14
15
SWAP
PIP
POP/PBP
PIP POS
CHANGE SCREEN IF YOU SEE
TWO WINDOW ON DTV
PICTURE IN PICTURE
PICTURE ON PICTURE /
PICTURE BY PICTUER
CHANGE POSITION
(1/4,2/4,3/4,4/4) EFBE10000369E9111100010F
EFBE10000328211111000110
EFBE100003E9E11111000111
EFBE10000329F31111000128
16
17
18
ASPECT
GUIDE
INFO
CHANGE MODE LIKE
4:3,WIDE,FULL,STD
SHOW EPG(ELECTRIC
PROGRAM GUIDE) ONLY DTV
SHOW INFORMATION WHERE
YOU EXIST LOCATION EFBE100003E9E4111100011D
EFBE100003A9E5111100011E
EFBE100003A829111100010E
19 SLEEP CHANGE TIME ABOUT
SLEEPING TIME EFBE100003E8331111000129
20
21 CC_ON
CC_OFF TURN ON CC
TURN OFF CC EFBE100003E8391111000131
EFBE100003A8381111000132
22
23
24
25
26
27
CAPTION
0
1
2
3
4
TURN ON / OFF CAPTION (ON<-
> OFF<-> MUTE)
KEY
EFBE100003A9E01111000112
EFBE10000368201111000113
EFBE10000329E21111000114
EFBE100003E8221111000115
EFBE100003A8231111000116
EFBE10000369E31111000117
