42 Using Your NAS System
6 Click File Screening ManagementFile Screens.
7 Either right-click or use Create File Screen option from the right pane.
8 Follow the wizard, select the path (volume or folder in which you want to
create the file screen), select your preferred File Screen Properties and
click Create.
The newly-created file screen is displayed in the central pane.
9 Select any of the existing file screens and right-click or use the options in
right-most panes to change the file screen properties.
Creating a New Volume
Perform the following configuration steps.
NOTE: Backup Operator or Administrator is the minimum membership required to
perform this configuration.
1 From your NAS system or remote desktop, open disk management, select
the Rescan Disks option.
The central pane lists the LUNs of storage located on your NAS system.
NOTE: The default status for the newly-created LUN in Disk management is
Unknown and Offline.
2 Select the Disk, right-click, and select the Online option.
Now the disk is seen as Unknown and Not Initialized.
3 Select the Disk, right-click, and select the Initialize Disk option. In the
Initialize Disk dialog box, select the disk(s) to initialize.
A pop-up window to select the partition style for the selected disks is
displayed with the following options:
a MBR (Master Boot Record)
b GPT (GUID Partition Table)
4 Select a partition style and click OK.
NOTE: The disk is initialized as a basic disk.
5 In the middle pane, select the disk and run the New Simple Volume…
wizard.
