Optical Drive
Dell™ Inspiron™ 1420/Dell Vostro™ 1400
Service Manual
Removing the Optical Drive
Replacing the Optical Drive
Removing the Optical Drive
1. Follow the procedures in Before You Begin .
2. Turn the computer over.
3. Remove the locking screw from the optical drive.
4. Using a plastic scribe, push the notch to release the optical drive from the bay.
5. Slide the optical drive out of the bay.
Replacing the Optical Drive
1. Slide the optical drive into the bay.
2. Replace and tighten the locking screw.
Back to Contents Page
CAUTION: Before you begin any of the procedures in this section, follow the safety instructions in the Product Information Guide.
1 optical drive 2 locking screw 3 notch
