Replacing the display bezel, Removing the display panel – Dell Vostro 1400 (Mid 2007) User Manual
Page 17
Replacing the Display Bezel
1.
Follow the instructions in
Before You Begin
.
2.
Follow the instructions in
3.
Starting near the hinges (near the Dell logo), use your fingers to snap the new bezel into place.
4.
Replace the six M2.5 x 5-mm screws to secure the bezel.
5.
Replace the six rubber bumpers to cover the screws.
6.
Replace the display assembly (see
Replacing the Display Assembly
Removing the Display Panel
1.
Follow the instructions in
Before You Begin
.
2.
).
3.
).
4.
Remove the two screws securing the display panel to the display cover.
CAUTION:
Before you perform any of the procedures in this section, follow the safety instructions in the Product Information Guide.
NOTICE:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface, such as the back panel on the computer.
CAUTION:
Before you perform any of the procedures in this section, follow the safety instructions in the Product Information Guide.
NOTICE:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface, such as the back panel on the computer.
1
screws (2)
2
display panel
3
display cover
