Reserve Battery
Dell™ Inspiron™ 510m Service Manual
1. Follow the instructions in " Preparing to Work Inside the Computer ."
2. Remove the battery .
3. Depress the battery latch and rotate it out to remove the reserve battery cover.
4. Pull the reserve battery straight out of the computer base.
5. Disconnect the reserve-battery cable connector from the battery connector.
Back to Contents Page
CAUTION: Before working inside your Dell™ computer, read the safety instructions in your Owner's Manual.
CAUTION: To prevent static damage to components inside your computer, discharge static electricity from your body before you touch any of
your computer's electronic components. You can do so by touching an unpainted metal surface.
1 reserve battery cover
1 battery connector
2 reserve battery
