28 | Removing the Wireless Mini-Card
Removing the Wireless Mini-Card
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 7. After working inside your computer, follow the instructions in "After
Working Inside Your Computer" on page 9. For additional safety best
practices information, see the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.
Prerequisites
1 Remove the battery. See "Removing the Battery" on page 10.
2 Follow step 1 to step 2 in "Removing the Memory Module(s)" on page 12.
3 Follow step 1 to step 2 in "Removing the Optical-Drive Assembly" on page 15.
4 Remove the keyboard. See "Removing the Keyboard" on page 21.
5 Remove the palm rest. See "Removing the Palm Rest" on page 24.
Procedure
1 Disconnect the antenna cables from the wireless mini-card.
2 Remove the screw that secures the wireless mini-card to the system board.
1 screw 2 antenna cables (2)
3 wireless mini-card
1
3
2
