Dell 1710/n Mono Laser Printer - Manual (Page 53)

Printing
5 3
3 From the Page Layout tab, click More Page Layout Options.
4 Click Poster.
5 Select the poster size you want by choosing the number of pages to use in the poster.
6 To print crop marks on the pages, select Print crop marks.
7 Select the amount of overlap you want each page to have.
8 Click OK twice.
9 Click OK on the Print window to send the job to print.
Printing on Letterhead
To print on letterhead, make sure the paper is loaded with the proper orientation.
1 Make sure the letterhead is properly loaded according to the paper source you are using:
• Tray 1 or 2—Load the letterhead paper with the design side facing down. The top edge
of the sheet with the logo should be placed at the front of the tray.
• Manual feeder—Load the letterhead paper face-up, with the top of the sheet first.
NOTE: If you are using the manual feeder, first send the job to print, then load the letterhead when
the printer displays the Load Manual Feeder light sequence (see "Manually Feeding a Print Job" on
page 47).
2 From the computer’s software application, select File
→
Print.
3 Click Properties (or Options, Printer, or Setup, depending on the application) to view the
printer driver settings.
4 Click the Paper tab.
5 Select Letterhead from the Paper type drop-down lists.
6 Select the appropriate paper size and tray.
7 Click OK.
8 Click OK on the Print window to send the job to print.
