Removing the mSATA Card | 15
Removing the mSATA Card
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before Working Inside
Your Computer" on page 5. After working inside your computer, follow the
instructions in "After Working Inside Your Computer" on page 7.
For more safety best practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Prerequisites
1 Remove the base cover. See "Removing the Base Cover" on page 8.
2 Remove the battery. See "Removing the Battery" on page 11.
Procedure
1 Remove the screw that secures the mSATA card to the palm-rest assembly.
2 Slide the mSATA card out of the mSATA-card connector.
1 screw 2 mSATA card
3 mSATA-card connector
1
3
2
