14 | Replacing the Wireless Card
Replacing the Wireless Card
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before Working Inside
Your Computer" on page 5. After working inside your computer, follow the
instructions in "After Working Inside Your Computer" on page 7.
For more safety best practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Procedure
CAUTION: To avoid damaging the wireless card, do not place any cables under it.
1 Align the notch on the wireless card with the tab on the wireless-card connector.
2 Insert the wireless card at an angle into the wireless-card connector.
3 Press the other end of the wireless card down and replace the screw that secures
the wireless card to the system board.
4 Connect the antenna cables to the wireless card.
The following table provides the antenna-cable color scheme for the wireless card
supported by your computer.
5 Adhere the conductive tape to the antenna cables.
Postrequisites
1 Replace the battery. See "Replacing the Battery" on page 12.
2 Replace the base cover. See "Replacing the Base Cover" on page 10.
Connectors on the wireless card Antenna-cable color
Main (white triangle)
Auxiliary (black triangle)
white
black
