Replacing the Middle Cover
1. Follow the instructions in Before You Begin .
2. Align the four tabs on the middle cover with the slots on the computer base and snap the middle cover into place.
3. Replace the display assembly (see Replacing the Display Assembly ).
4. Replace the palm rest (see Replacing the Palm Rest ).
5. Replace the keyboard (see Replacing the Keyboard ).
6. Turn the computer over.
7. Replace the three screws that secure the middle cover to the computer base.
8. Replace the module cover (see Replacing the Module Cover ).
9. Replace the battery (see Replacing the Battery ).
Back to Contents Page
1 middle cover
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
