MB, or 1-GB unbuffered ECC memory modules in the four memory module sockets on the system board
l Support for the following internal hard-drive (non-hot-plug) configurations:
¡ Up to two internal 1-inch SATA hard drives with an integrated SATA controller
or
¡ Up to two internal 1-inch SCSI hard drives with a SCSI controller card
l One 3.5-inch peripheral drive bay for the optional diskette drive, and two 5.25-inch bays for the following supported drives: CD, DVD, combination CD-
RW/DVD, DVD-RW (data only), or tape backup device
l Support for software RAID level 1
l Support for USB 2.0
l Chassis intrusion alert
The system board includes the following built-in features:
l Dual-channel IDE controller that supports up to two supported devices including IDE CD, DVD, CD-RW/DVD combination drive, or DVD-RW, and an IDE
tape backup device
l SATA controller that supports up to two cabled SATA hard drives
l Three 32-bit, 33-MHz I/O expansion card slots, one 2.5-GHz PCIe x1 expansion slot, and one 2.5-GHz PCIe x8 expansion slot
l Embedded video with 8 MB of SDRAM video memory (nonupgradable), and a maximum resolution of 1600 x 1280 pixels and 16.7 million colors
(noninterlaced)
l An integrated Gigabit Ethernet NIC, capable of supporting 1000-Mbps, 100-Mbps, or 10-Mbps data rates, with support for PXE and Wake-on-LAN
The following software is included with your system:
l The System Setup program for quickly viewing and changing the system configuration information for your system. For more information on this
program, see " Using the System Setup Program ."
l Enhanced security features, including a system password and a setup password, available through the System Setup program.
l Diagnostics for evaluating your system's components and devices. For information on using the system diagnostics, see "Running the System
Diagnostics" in your Installation and Troubleshooting Guide.
For more information about specific features, see " Technical Specifications ." For a list of documents that provide more information on your system's features,
see " Other Documents You May Need ."
Supported Operating Systems
Your system supports the following operating systems:
l Microsoft® Windows® Server 2003, Standard Edition
l Windows Small Business Server 2003
l Red Hat® Enterprise Linux ES (Version 3)
Power Protection Devices
Certain devices protect your system from the effects of problems such as power surges and power failures.
l PDU — Uses circuit breakers to ensure that the AC current load does not exceed the PDU's rating.
l Surge protector — Prevents voltage spikes, such as those that may occur during an electrical storm, from entering the system through the electrical
outlet. They do not protect against brownouts, which occur when the voltage drops more than 20 percent below the normal AC line voltage level.
l Line conditioner — Maintains a system's AC power source voltage at a moderately constant level and provides protection from brownouts, but does not
protect against a complete power loss.
l UPS — Uses battery power to keep the system running when AC power is unavailable. The battery is charged by AC power while it is available so that
after AC power is lost, the battery can provide power to the system for a limited amount of time—from 5 minutes to approximately an hour. A UPS that
provides only 5 minutes of battery power allows you to save your files and to shut down the system. Use surge protectors and PDUs with all universal
power supplies, and ensure that the UPS is UL-safety approved.
Other Documents You May Need
NOTE: DVD devices are data only.
NOTE: DVD devices are data only.
