PS/2-compatible mouse 6-pin mini-DIN
Serial 9-pin, DTE, 16550-compatible
USB Two 4-pin, version 2.0
Video 15-pin VGA
Front
USB Two 4-pin
Internally accessible
IDE channels Two 40-pin
SATA channels Two 7-pin
Video
Video type Embedded
Video memory 8 MB
Power
AC power supply
NOTICE: Ensure that the voltage selection switch on the power supply is set to the appropriate voltage
before turning on the power. See Figure 1 -2 for the location of the switch.
Wattage 305 W
Voltage 115–230 VAC, 60/50 Hz, 7.0–3.5 A
Heat dissipation 1040 BTU/hr maximum
Maximum inrush current (115 VAC) Under typical line conditions and over the entire
system ambient operating range, the inrush current
may reach 35 A for 10 ms or less.
Maximum inrush current (230 VAC) Under typical line conditions and over the entire
system ambient operating range, the inrush current
may reach 70 A for 10 ms or less.
Batteries
System battery CR 2032 3.0-V lithium ion coin cell
Physical
Height 49.1 cm (16.77 in)
Width 22.2 cm (7.5 in)
Depth 48.8 cm (17.67 in)
Weight (maximum configuration) 19 kg (41.9 lb.)
Environmental
NOTE: For additional information about environmental measurements for specific system configurations, see
www.dell.com/environmental_datasheets.
Temperature
Operating 10° to 35°C (50° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity
Operating 8% to 85% (noncondensing) with a maximum
humidity gradation of 10% per hour
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.25 G at 3–200 Hz for 15 min.
Storage 0.5 G at 3–200 Hz for 15 min.
Maximum shock
Operating One shock pulse in the positive z axis (one pulse on
each side of the system) of 41 G for up to 2 ms
Storage Six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse on
each side of the system) of 71 G for up to 2 ms
