Removing the Optical Drive | 15
3 Remove the screw that secures the optical-drive bracket to the
optical-drive assembly and remove the optical-drive bracket.
4 Carefully pull the optical-drive bezel and remove it from the optical drive.
1 optical-drive bezel 2 optical drive
3 screw 4 optical-drive bracket
4
1 3
2
