Ports and Connectors
• one eSATA/USB 2.0–compliant
connector
Memory card reader smart card/SD card/ExpressCard
IEEE 1394 4-pin connector
HDMI 19–pin connector
Display
Type HD WLED
Brightness 198 nits, 306 nits
Size 13.30 inches
Active area (X/Y) 293.42 mm (H) x 164.97 mm (V)
Dimensions: 307.60 mm (H ) x 183.10 mm (V)
Height 307.60 ± 0.50 mm
Width 183.10 ± 0.50 mm
Z-Height (max) 5.50 mm
Diagonal 13.30 inches
Maximum resolution 1366 x 768
Operating angle
Laptop mode 5° to 180°
Tablet mode 0° (closed) to 180°
Refresh rate 60 Hz
Minimum Viewing angles:
Horizontal 60/60 degrees
Vertical 50/50 degrees
Pixel pitch 0.2148 mm × 0.2148 mm
Keyboard
Number of keys
• United States and Canada : 83
• Europe: 84
