Specifications
Dell™ Vostro™ Service Manual
NOTE: Offerings may vary by region. For more information regarding the configuration of your computer, click Start® Help and Support and select the
option to view information about your computer.
System Information
Memory
Audio
ExpressCard
Display
Touch Pad
AC Adapter
Environmental
Processor
Video
Communications
Ports and Connectors
Keyboard
Battery
Physical
System Information
Chipset Mobile Intel® GS45 Express Chipset
DRAM bus width 64-bit buses
Processor address bus width 36 bits
Flash EPROM SPI 16 Mbits
PCI bus 32 bits, 33 MHz
Processor
Types Intel® Celeron® Ultra Low Voltage (ULV)
Intel Core™2 Solo ULV
Intel Core2 Duo ULV
L2 cache Intel Celeron ULV–1MB
Intel Core2 Solo ULV–3 MB
Intel Core2 Duo ULV–3 MB
External bus frequency 800 MHz
Memory
Type DDR3 SDRAM
Speed 1067 MHz
NOTE: The memory runs at 800 MHz due to the
limitations of the Front Side Bus (FSB).
Connectors one user-accessible SODIMM socket
Module capacities 1 GB, 2 GB, and 4 GB
Minimum memory 1 GB
Maximum memory 4 GB
Video
Type integrated on system board
Controller and memory Intel GMA X4500HD
Output 15-pin VGA connector
Audio
Type two-channel high definition audio
Controller Realtek ALC269
Stereo conversion 24-bit (analog-to-digital and digital-to-analog)
Interface:
Internal high definition audio
External microphone-in connector, stereo
headphones/external speakers connector
Speakers 1.5 W mono
