Page 10: Physical

background image

Y-axis

40.7 mm



Battery

Type

6-cell "smart" lithium-ion (30 WHr)

Charge time with computer off

approximately 4 hours (on a fully discharged battery)

Operating time

battery operating time varies depending on operating
conditions and can significantly reduce under certain
power-intensive conditions.

Life span

approximately 300 charge/discharge cycles

Dimensions:



Depth

155.20 mm (6.11 inch)

Height

5.65 mm (0.23 inch)

Width

177.60 mm (6.99 inch)

Voltage

11.10 VDC

Temperature range:



Operating

0 °C to 35 °C (32 °F to 95 °F)

Storage

–40 °C to 65 °C (–40 °F to 149 °F)

Coin-cell battery

3 V CR2032 lithium



AC Adapter

Type



Input voltage

100–240 VAC

Input current (maximum)

1.5 A

Input frequency

50–60 Hz

Output current

4.34 A (maximum at 4-second pulse)
3.34 A (continuous)

Output voltage

19.5 +/– 1.0 VDC

Dimensions:



Height

16 mm (0.63 inch)

Width

66 mm (2.60 inch)

Depth

127 mm (5.00 inch)

Temperature range:



Operating

0° C to 35° C (32° F to 95° F)

Storage

–40 °C to 65 °C (–40 °F to 149 °F)



Physical

Height (front to back)

16.5 mm to 19.7 mm (0.65 inch to 0.78 inch)

Width

330 mm (12.99 inch)

Depth

230 mm (9.05 inch)

Weight (with 6-cell battery)

<1.6 kg (<3.53 lb)



Environmental

Temperature range:



Operating

0° C to 35° C (32° F to 95° F)

Storage

–40° C to 65° C (–40° F to 149° F)

Relative humidity (maximum):



Operating

10% to 90% (noncondensing)

Storage

5% to 95% (noncondensing)

Maximum vibration:



Operating

0.66 Grms (2–600 Hz)

Storage

1.30 Grms (2–600 Hz)

NOTE:

Vibration is measured using a random-vibration spectrum that simulates user environment.

Maximum shock:



Operating

142 G (2 ms)

Storage

162 G (2 ms)
