Page 35
INSTALLATION CHECK-OUT
FOT-F3 USER’S MANUAL
4-3
4.1.2
Testing the FOT-F3 Fiber Optic Transceiver
Two Ethernet node testers capable of generating valid data
packets, such as the LAN-MD, are required for this procedure.
Refer to Figure 4-1 and proceed as follows:
1.
Using an AUI cable (2), connect a LAN-MD (1) to the
FOT-F3 (3).
Figure 4-1 Installation Checkout
1 2 3 4 5
6 7
1. LAN-MD
2. AUI Cable
3. FOT-F3
4. Fiber Optic Segment
5. FOT-F3
6. AUI Cable
7. LAN-MD
0461-10
