9-50 Vehicle Care
Mini-Fuses Usage
PWR
MODING
PassKey Module,
Body Control
Module
PWR
OUTLET
Console Auxiliary
Power Outlet
RT
HI BEAM
Right High-Beam
Headlamp
RT
LO BEAM
Right Low-Beam
Headlamp
RT
LO BEAM
Right Low-Beam
Headlamp
SPARE Spare
STR/WHL/
CNTRL
Steering Wheel
Illumination
TCM BATT
Transmission
Control Module
Battery
TOSS/BRK
VAC RLY
Transmission Output
Speed Sensor/Brake
Vacuum Relay
WPR Windshield Wiper
J-Case
Fuses
Usage
ABS MTR ABS Motor
BLWR Blower
BRK
VAC PUMP
Brake
Vacuum Pump
EPB Electric Park Brake
FAN 1 Cooling Fan 1
FAN 2 Cooling Fan 2
REAR
DEFOG
Rear Defogger
SPARE Spare
STRTR Starter
TRLR Trailer Towing
WSW/HTR Not Used
Relays Usage
A/C
CMPRSR
Air Conditioning
Compressor Clutch
DRL
(W/O HID)
LO BEAM
(HID)
Daytime Running
Lamps (without High
Intensity Discharge),
Low-Beam
Headlamps (High
Intensity Discharge)
FAN S/P
Cooling Fan
Series/Parallel
FAN 1 Cooling Fan 1
FAN 2 Cooling Fan 2
FOG LAMP Fog Lamps
HDLP
WASH
Headlamp Washer
HI BEAM
High-Beam
Headlamp
HORN Horn
IGN 1 Ignition 1
