9-44 Vehicle Care
J-Case
Fuses
Usage
FAN 1 Cooling Fan 1
FAN 2 Cooling Fan 2
REAR
DEFOG
Rear Defogger
STRTR Starter
SPARE Spare
WSW/HTR Not Used
Relays Usage
A/C
CMPRSR
Air Conditioning
Compressor Clutch
DRL
(W/O HID)
LO BEAM
(HID)
Daytime Running
Lamps (without High
Intensity Discharge),
Low-Beam
Headlamps (High
Intensity Discharge)
Relays Usage
FAN S/P
Cooling Fan
Series/Parallel
FAN 1 Cooling Fan 1
FAN 2 Cooling Fan 2
FOG LAMP Fog Lamps
HDLP
WASH
Not Used
HI BEAM
High-Beam
Headlamp
HORN Horn
IGN 1 Ignition 1
LO BEAM
(W/O HID)
LT DRL
(HID)
Low-Beam (without
High Intensity
Discharge), Left
Daytime Running
Lamp (High Intensity
Discharge)
Relays Usage
PWR/TRN Powertrain
REAR
DEFOG
Rear Defogger
RT
DRL (HID)
Right Daytime
Running Lamp
(High Intensity
Discharge)
SPARE Spare
STRTR Starter
WPR Windshield Wiper
WPR HI
Windshield Wiper
High Speed
WSW
Windshield
Washer Pump
